PowerEdge C4140 Server
PowerEdge C4140 Server
Accelerator-Optimized, High-Density Server
Meet the demands of cognitive computing workloads with a dense, accelerator-optimized 1U server supporting 4 GPUs and superior thermal efficiency.
| Tech Specs & Customization | |
|---|---|
| Processor | Two 2nd generation Intel® Xeon® Scalable processors: up to 24 cores per processor |
| Operating System | Canonical® Ubuntu® Server LTS Red Hat® Enterprise Linux SUSE® Linux Enterprise Server |
| Memory | DIMM Speed Up to 2933MT/s Memory Type RDIMM 8GB, 16GB, 32GB LRDIMM 64GB, 128GB Memory Module Slots 24 DIMMs Maximum RAM RDIMM 1.5TB LRDIMM 1.5TB |
| Management | Embedded / At-the-Server iDRAC9 iDRAC RESTful API with Redfish Consoles OpenManage Enterprise OpenManage Power Center Mobility OpenManage Mobile |
| Embedded / At-the-Server | iDRAC9 iDRAC RESTful API with Redfish |
| Consoles | OpenManage Enterprise OpenManage Power Center |
| Mobility | OpenManage Mobile |
| Tools | Dell Technologies RACADM CLI Dell Technologies Repository Manager Dell Technologies System Update Dell Technologies Server Update Utility Dell Technologies Update Catalogs iDRAC Service Module IPMI Tool OpenManage Server Administrator OpenManage Storage Services |
| OpenManage Integrations | BMC Truesight Microsoft® System Center RedHat® Ansible® Modules VMware® vCenter |
| OpenManage Connections | IBM Tivoli® Netcool/OMNIbus IBM Tivoli® Network Manager IP Edition Micro Focus® Operations Manager I Nagios® Core Nagios® XI |
| Power Supplies | 2000W Platinum 2400W Platinum Hot-plug power supplies with full redundancy option |
| Regulatory | Product Safety, Technologies and Environmental Datasheets Dell Regulatory Compliance Home Page Dell and the Environment |
| Security | Cryptographically signed firmware Secure Boot Secure Erase Silicon Root of Trust System Lockdown (requires OpenManage Enterprise) TPM 1.2/2.0, TCM 2.0 optional |
| Storage Controllers | Internal Boot Boot Optimized Storage Subsystem (BOSS) HW RAID 2 x M.2 SSDs 240GB or 480GB Form Factor 1U Rack Server |
| Dimensions & Weight | Height 428.0mm (1.7″) Width 434.0mm (17.1″) Depth 9262.0mm (36.5″) Weight 24.0kg (52.9lbs.) |
| Recommended Support | Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region. |
| Slots | PCIe 2 x Intel 10GbE adapter 2 x Intel 25GbE adapter 1 x Intel omni-path single port host fabric adapter 100 series LP PCIe adapter 1 x Mellanox ConnectX-4 single port VPI QSFP28 1 x EDR LP PCIe adapter 1 x Mellanox ConnectX-4 dual port VPI QSFP28 EDR LP PCIe adapter 2 x NVMe/PCIE SSD AIC in rear slots, 1.6/3.2/6.4TB (supported) Support for the following PCIE NW adaptors Mellanox ConnectX-4 Single Port VPI QSFP28 EDR LP PCIe Adapter Mellanox ConnectX-4 Dual Port VPI QSFP28 EDR LP PCIe Adapter Intel Omni-Path Single Port Host Fabric Adapter 100 Series LP PCIe Adapter Intel 2x 10GbE adapter Intel 2x 25GbE adapter |
| Accelerators | 4 NVIDIA GPUs Tesla V100 or V100S including SXM2 with NVLink inter-connectivity |
| Ports | Network Options 1 x 10GbE Intel Quad Port (2+2) Base-T NDC 1 x Intel 10GbE Intel Quad Port SFP+ (2+2) NDC Front Ports 1 x Health status LED 1 x Power button system ID/status LED Rear Ports 1 x iDRAC ethernet port 2 x USB 3.0 ports |
Product Details
Designed for the most demanding cognitive and technical computing
Give challenging cognitive computing workloads what they need with this high-density, accelerator-optimized server. The PowerEdge C4140 provides maximum density and outstanding thermal efficiency for scale-out performance. Speed up your applications with four GPUs/FPGAs in a 1U, 2-socket package.- Ideal for:
- Big data analytics
- Artificial intelligence (AI)
- Machine learning
- Deep learning
- High-performance technical computing
Increase performance with flexible accelerator technology
The PowerEdge C4140 is an incredibly dense rack server designed to handle the most demanding technical computing workloads in financial services, life sciences, machine and deep learning, oil and gas exploration, and high-performance computing (HPC).- Features the latest generation of Intel® Xeon® Scalable Processors at 165W thermal design power (TDP).
- The C4140 delivers un-throttled performance with its unique interleaved GPU design and no-compromise acceleration technology.
- Supports up to 300W per accelerator card.
Gain productivity with intelligent, embedded management
Dell Technologies OpenManage intelligent automation enables you to spend less time on routine maintenance so you can focus on business-critical priorities.- Help maximize uptime and reduce the IT effort to resolve issues by up to 72%* with ProSupport Plus and SupportAssist.
- Leverage existing management consoles with easy integrations for VMware® vSphere®, Microsoft® System Center and Nagios®.
- Improve productivity with agent-free Dell Technologies iDRAC9 for efficient management.
- Simplify deployment with OpenManage next-generation console and server profiles to fully configure and prep servers rapidly and scalably.
Fortify your data center with comprehensive protection
A comprehensive, cyber-resilient architecture with security embedded into every server helps to protect your data.- Protect server configuration and firmware from malicious changes with new Configuration Lock-down.
- Use system erase of local storage to help insure data privacy when you repurpose or retire servers.
- Automate updates that check file dependencies and proper update sequence, before deploying them independently from the OS/hypervisor.
- Take control of your firmware consoles with embedded authentication that is designed to allow only properly signed updates to run.
